Humboldt Load Frame HM-5030U
Product SKU : HM-5030U
Country : USA
Now you can upgrade your old HM-3000.3F Master Loader to the New HM-5030.3F Elite Series Master Loader. Upgrade requires you to ship back your current machine, which will be altered to create a new HM-5030.3F Elite Series Master Loader.
Designed for applications requiring multi-purpose loading systems, such as road construction projects in either mobile or fixed labs, educational institutions and consulting firms, the HM-5030 Master Loader is ideal for just about any application from road construction to high-volume commercial and educational laboratories.
While the HM-5030 has been specifically designed for soil testing labs conducting multiple testing operations including: UU, CU and CD triaxial, UC, CBR and LBR, it is also perfect for running Marshall, Hveem, TSR and SCB asphalt tests as well. Its heavy-duty design and precise stepper-motor control provide a stable platform for years of reliable service allowing the HM-5030 to perform any tests required up to its load capacity of 11000 lbf (50kN).
Like all elite series load frames, the HM-5030 is built around Humboldt's integral, 4-channel data logger with touch-screen control, which allows the load frame to be used as a standalone device capable of full test control and data logging. It can also be controlled by a networked computer at any location with access to the network.
The HM-5030 provides four (4) integral and independent data acquisition channels, which can be utilized in stand-alone configurations or accessed through a LAN-networked computer using Humboldt's Next Software.The HM-5030 load frame is built with durable, high-quality components and features the use of a stepper motor, precision gears and gear box to ensure smooth and reliable operation, as well as precise results.
In stand-alone mode, the HM-5030 load frame provides a 7" (178mm) touch-screen controller, giving you finger-tip control of your testing processes, as well as providing real-time, visual views of your data in both tabular and graphic formats. This waterproof, touch screen provides colorful, at-a-glance monitoring of testing functions without the use of a computer. Operators can see all the data in several formats at the machine while the test is running. Data can then be viewed simultaneously or downloaded later to a computer in the lab, in the next room or at a different location, while also providing report generation capabilities from within Humboldt's NEXT software or our enhanced test-specific modules.
Contact Us
09-5025972, 09-443087709, 09-777258535, 09-254629088, 09-403997619
This email address is being protected from spambots. You need JavaScript enabled to view it.
Touch-screen controller provides:
• 4-channel data acquisition
• Hi-res, 7", waterproof, touch-screen provides total control and real-time graphical display of tests
• Machine /Test control and data acquisition via touch-screen
• Control up to 4 different tests at the same time
• Calibration of channels to load cells, transducers and other suitable instruments
• Real-time graphical chart and numerical display of tests via touch-screen display
• Effective sampling rate of 50 readings per second
• Stores up to 1000 tests with 3000 points per test
• 2 USB ports. One in front for data transfer and the rear port is for powering a wireless access point.
When operated from a networked computer the NEXT software provides robust machine and test control, as well as report generation. It also provides the ability to control and monitor multiple machines from a single computer.
Humboldt's next software provides:
• Machine control, and data acquisition via networked computer
• Provides the ability to use Next Software's, advanced test-specific modules
• Real-time graphical chart and numerical display of tests via computer display
• Effective sampling rate of 50 readings per second
• Stores unlimited tests with up to 3000 points per test
• Up to 255 individual tests can be run simultaneously from a single PC
• Advanced, test-specific modules are available, which provide all the calculations and graphs required per testing standards
• Provides advanced graphing capabilities
• Provides full-unit customization
• Reports can also be exported to Excel or a CSV file, if desired, and, we can provide custom integration/export solutions for LIMS, EQuIS, gINT, etc
• For additional information about the Elite Series Load Frames, click here.
